IBR Boiler

I. AFBC Boiler

CAPACITY UPTO 175TPH
PRESSURE UPTO 105 KG/CM2
STEAM TEMP UPTO 525°C
FUEL RICE HUSK, COAL, LIGNITE, WASHERY, REJECTS, CHAR ETC.

Salient Features

- Bi-drum / Single Drum, Water Tube, Natural circulation top / bottom supported design.
- Better Evaporator Design for better reliability.
- Suitable for saturated and superheater steam. Suitable for Cogeneration and Captive Power Plants.
- Multifuel firing options.
- Underbed / Overbed fuel feed system.
- Bottom Hopper Design for specific applications.
- Optimum combustion with staged Secondary Air System.




II. Grate Fired Boilers

a) Traveling Grate (TG)

CAPACITY UPTO 170TPH
PRESSURE UPTO 110 KG/CM2 (g)
STEAM TEMP UPTO 520°C
FUEL Baggase, Rice Husk, Cotton Stalk, Mustard Stalk, Wood Chips, Paddy Straw, Coal, Lignite etc.

Salient Features

- Continuous Ash Discharge.
- Bi-Drum/Single Drum Design, Natural Circulation, Top Supported Design.
- Tall Furnace for Stagged/Complete Combustion.
- Optimum combustion with staged secondary air system.
- 2 Stage/3Stage Superheater with inters-tage Spray Attemperator.
- Even Fuel Distribution on the Entire Grate.
- Modulating Cyclo motor for Spreader Dampers. - Grate Driven by Hydraulic Drive/ Mechanical Drive.


b) Dumping Grate (DG)

CAPACITY UPTO 175TPH
PRESSURE UPTO 110 KG/CM2
STEAM TEMP UPTO 540°C
FUEL BAGASSE, RICE HUSK ETC.

Salient Features

- Generously sized grate.
- Soot Blowers for on load cleaning of heating surface.
- Secondary air distribution system.
- Pneumatically operated sectionalized dumping grate.
- Two stage superheaters with single stage attemperator for accurate steam temperature control.


c) Pulsating Grate (PG)

CAPACITY UPTO 50TPH
PRESSURE UPTO 67 KG/CM2
STEAM TEMP UPTO 490°C
FUEL RICE HUSK, BAGASSE, MUSTARD HUSK, COTTON STALK, OTHER BIO-MASS FUELS AND BREQUETS, ETC.

Salient Features

- Generously sized grate.
- Soot Blowers for on load cleaning of heating surface.
- Secondary air distribution system.
- Hydraulically operated sectionalized pulsating grate.
- Two stage superheaters with single stage attemperator for accurate steam temperature control.
- Continuous Ash discharge.





III. Process Boilers

a) Hypac Boiler

CAPACITY UPTO 15 TPH
PRESSURE UPTO 25 KG/CM2
FUEL RICE HUSK, COAL, PETCOKE, LIGNITE ETC.

Salient Features

- Water cum smoke tube boilers.
- Capacity upto 15 TPH
- Easily takes the variation of load fluctuations
- Burn agriculture residue and other high volume low density fuels
- Can be equipped with fluidized bed, moving and stationery grate furnace
- Four side water wall design available


b) Inpac Boiler

Inpac is a packaged, three-pass smoke tube, with fully wet back boiler. Inpac comes in two series for Wood & Biomass and other for Coal. It can also be customized to a completely skid mounted unit on customer demand.

PRODUCT FEATURES

- Three-pass smoke tube with fully wet back boiler.
- Multi-fuel option Wood/Briqutte/Baggase/Coal.
- High efficiency of about 70% to 74%.
- High dryness fraction steam increases usable heat.
- Large water holding capacity.
- Plain Single furnaces for boiler upto 4 TPH capacity.


c) Energypac Boiler

CAPACITY UPTO 15TPH
PRESSURE UPTO 25 KG/CM2
FUEL WOOD, PLYWOOD WASTE, BAGASSE, COAL, MUSTARD HUSK AND OTHER BIOMASSFUELS.

Salient Features

- Similar to Hypac boiler except having equipped with large grate to burn high moisture fuel like wood chips and other agro wastes
- High Efficiency: Paneled water wall furnace and three pass design absorbs maximum heat
- Dry Steam: Large water-steam interface area ensures dry steam
- Multi-fuel option: Wood, briquettes, coal, agro waste, etc


d) Oil Pac Boiler

CAPACITY 1 TPH - 20 TPH
PRESSURE 10.54 KG/CM2 TO 17.5 KG/CM2
FUEL Oil, Gas QUANTITY MANUFACTURED 20 NOS

Salient Features

- Standard design integral furnace boiler suitable for burning heavy and light fuel, oils including gas
- Multipass fire tube design
- Three pass, fully automatic, wetback design
- Designed to give overall efficiency of 88% on NCV
- Dryness fractions to the order of 0.985 achievable


e) Effypac Boiler

CAPACITY 500,1000,1500,2000 Kg/hr
PRESSURE Upto 17.5 Kg/cm²
STEAM TEMP Saturated Steam
FUEL Coal, Wood, Agro Waste, Briquettes etc.

Salient Features

- Plug & Steam Unit need only water, power & Chimney.
- Skid mounted design not requiring any structure, Water tank, insulation, ducting, refractory etc.
- Compact design suitable for industries with less space.
- Inbuilt HRU for high efficiency.
- Cyclone included in package for controlling outlet dust concentration.
